サーバの管理ボードをリセットする ipmitool mc reset cold | Linux | マイノリティでいこう
今更ながら手元の環境で、SMCへ接続できなかったのでメモ。
手順
とりあえず、以下のようなコマンドを実行してやればよい。
オプションに「-vv
」を付けると詳細がわかりやすい。
ipmitool -H 192.168.1.1 -U root -P root mc reset cold -vv
結果は以下のように得られる。
Sending IPMI/RMCP presence ping packet
Received IPMI/RMCP response packet:
IPMI Supported
ASF Version 1.0
RMCP Version 1.0
RMCP Sequence 255
IANA Enterprise 4542
ipmi_lan_send_cmd:opened=[1], open=[2136939637]
Channel 01 Authentication Capabilities:
Privilege Level : ADMINISTRATOR
Auth Types : NONE MD2 MD5 PASSWORD
Per-msg auth : disabled
User level auth : enabled
Non-null users : enabled
Null users : disabled
Anonymous login : disabled
Proceeding with AuthType MD5
ipmi_lan_send_cmd:opened=[1], open=[2136939637]
Opening Session
Session ID : 02000100
Challenge : 301818186c7d7b8046386c79818f7986
Privilege Level : ADMINISTRATOR
Auth Type : MD5
ipmi_lan_send_cmd:opened=[1], open=[2136939637]
Session Activated
Auth Type : NONE
Max Priv Level : ADMINISTRATOR
Session ID : 02000200
Inbound Seq : 00000001
ipmi_lan_send_cmd:opened=[1], open=[2136939637]
Set Session Privilege Level to ADMINISTRATOR
ipmi_lan_send_cmd:opened=[1], open=[2136939637]
Iana: 7244
ipmi_lan_send_cmd:opened=[1], open=[2136939637]
IPM Controller is not HPM.2 compatible
Running Get PICMG Properties my_addr 0x20, transit 0, target 0x20
ipmi_lan_send_cmd:opened=[1], open=[2136939637]
Error Response 0xc1 from Get PICMG Properities
No PICMG Extenstion discovered
Specified addressing Target 0x20:0 Transit 0:0
Interface address: my_addr 0x20 transit 0:0 target 0x20:0 ipmb_target 0
ipmi_lan_send_cmd:opened=[1], open=[2136939637]
Sent cold reset command to MC
まぁ今更ベアメタルなサーバに触れる機会は少なくなっていると思いますが。
Supermicro IPMI 2.0 card / AOC
